16 Channel Network Video Recorder - Supports 16 IP POE Cameras

$1,099.99 after 20% promo after 20% promo $879.99
(You save $220.00)
Model: CSP-PROPOE16
Security Camera Recorder | IP Security Camera Network Video Recorder

Select your options:

superior products 3 year warranty
live usa technical support
30 day money back guarantee
free shipping on all orders over $100

Blue Line NVR Features Video


16 Channel POE NVR System with Stunning 4K Video

Unmatched Video Surveillance Solution for Businesses

When it comes to safeguarding your business or property, settling for anything less than the best is simply not an option. Our commercial-grade 32-Channel IP 4K NVR system offers unmatched surveillance capabilities that are guaranteed to meet and exceed your expectations. With advanced features and dynamic architecture, this state-of-the-art NVR delivers crystal-clear 4K Ultra HD images and videos, ensuring optimal security and peace of mind.

Superior Video Quality with 4K Ultra High Definition

Experience the power of 4K Ultra HD video surveillance with our 32-Channel IP NVR system. Every tiny detail, from the finest text to facial features, is captured with unprecedented clarity. Whether you need to identify a suspicious individual or monitor the overall activity, our NVR's high-quality video playback will provide you with the necessary visual evidence.

Easy Installation and Remote Access

Gone are the days of complex setup procedures and restricted access to your security footage. Our NVR system boasts a user-friendly plug-and-play installation, allowing you to effortlessly connect your cameras and start monitoring in no time. Additionally, you can conveniently access live and recorded camera footage remotely via your PC, smartphone, or tablet without any monthly fees. Stay in control and remain vigilant, no matter where you are.

Tailored Surveillance for Any Environment

Your surveillance needs are unique, and our 16 Channel NVR is as well. Whether you need to cover a large commercial building with dome security cameras or monitor a vast property with infrared bullet security cameras, our versatile NVR can accommodate your requirements. With the ability to connect up to 16 cameras, you can create a comprehensive surveillance network that leaves no blind spots.

Maximize Storage Efficiency with H.265 Video Compression

Storage space is a valuable resource when it comes to video surveillance. That's why our NVR recorder utilizes advanced H.265 video compression technology, which can save up to 40% of your hard drive space compared to traditional methods. Record more footage without worrying about running out of storage, and never compromise on the quality of your videos.

Seamless Integration and Expandability

Our PRO Series 16 Channel Network Video Recorder seamlessly integrates with our wide range of IP security cameras, offering you a cohesive and scalable security solution. Enhance your monitoring capabilities by adding specialized cameras such as PTZ cameras or vandal-proof cameras to address specific surveillance needs. With 4 hard drive bays, you have the flexibility to expand your storage capacity and capture every crucial moment.

Your Reliable Security Partner - CCTV Security Pros

Choosing the right security system is vital, and CCTV Security Pros stands out as the perfect partner for all your surveillance needs. By selecting our 16 Channel IP NVR, you gain access to numerous benefits that ensure your satisfaction and peace of mind.

  • 3-Year Product Warranty: Rest easy knowing that your investment is protected with our comprehensive 3-year product warranty, providing you with the support and reassurance you deserve.
  • 100% Money-Back Satisfaction Guarantee: We are confident in the quality and reliability of our products. If you're not completely satisfied, we offer a stress-free money-back guarantee with no restocking fees.
  • Free Shipping: Enjoy the convenience of free shipping on your NVR system, saving you both time and money.
  • Unlimited US-Based Technical Support: Our dedicated team of experts is here to assist you every step of the way. Take advantage of our unlimited technical support and get immediate assistance with any questions or concerns.
  • ONVIF Compliant: Our network video recorders are fully ONVIF compliant, ensuring compatibility with a wide range of security cameras, giving you the freedom to choose the cameras that best fit your needs.

Order Your 16 Channel Security Network Video Recorder Today

Don't compromise on your security. Take advantage of our reliable and performance-driven 32-Channel IP 4K NVR system from CCTV Security Pros. With our commitment to quality and customer satisfaction, you can build a robust security infrastructure and achieve the highest level of monitoring capabilities.



Discover why over 70,000 satisfied customers trust us for their security needs. Place your order for an IP network video recorder today or call our security experts at 888.653.2288 to discuss your unique requirements.





Technical Specification
System
Main Processor Industrial-grade processor
Operating System Embedded Linux
Operating Interface Web; Local GUI
AI
AI by Recorder Face detection, face recognition, perimeter protection, and SMD Plus
AI by Camera Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Perimeter Protection
Perimeter Performance AI by Recorder (Number of Channels) 2 channels, 10 IVS rules for each channel
Perimeter Performance of AI by Camera (Number of Channels) 8 channels
Face Detection
Face Attributes Gender; age group; glasses; expressions; face mask; beard
Face Detection Performance of AI by Recorder (Number of Channels) 1 channel (up to 12 face images/s each channel)
Face Detection Performance of AI by Camera (Number of Channels) 8 channels
Face Recognition
Face Database Capacity Up to 10 face databases with 20,000 images, with a total capacity of 2.5 G. Name, gender, birthday, address, credential type, credential No., countries & regions and state can be added to each face image.
Face Recognition Performance of AI by Recorder (Number of Channels) 8-channel FD (by camera) + FR (by recorder),image stream: 12 face images/s
1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
Face Recognition Performance of AI by Camera (Number of Channels) 8 channels
SMD Plus
SMD Plus by Recorder 4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change
SMD Plus by Camera 8 channels
Audio and Video
Access Channel 16 channels
Network Bandwidth AI disabled: 256 Mbps incoming, 256 Mbps recording and 256 Mbps outgoing
AI enabled: 180 Mbps incoming, 180 Mbps recording and 180 Mbps outgoing
Resolution 16 MP; 12 MP; 8 MP; 6 MP; 5 MP; 4 MP; 3 MP; 1080p; 960p; 720p; D1; CIF
Decoding Capability AI disabled: 2-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 4-channel 8 MP@30 fps; 6-channel 5 MP@30 fps; 8-channel 4 MP@30 fps; 16-channel 1080p@30 fps
AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps; 3-channel 8 MP@30 fps; 4-channel 5 MP@30 fps; 6-channel 4 MP@30 fps; 12-channel 1080p@30 fps
Video Output 1 HDMI, 1 VGA
HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
VGA: 1920 × 1080, 1280 × 1024, 1280 × 720
*Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.
Multi-screen Display 1st Screen: 1/4/8/9/16
2nd Screen: 1/4/8/9/16
Third-party Camera Access Panasonic, Sony, Samsung, Axis, Pelco, Arecont, ONVIF, Canon
Compression Standard
Video Compression Smart H.265+; H.265; Smart H.264+; H.264; MJPEG
Audio Compression G.711a; G.711u; PCM; G726
Network
Network Protocol HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; PPPoE; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS; etc.); P2P; auto register
Mobile Phone Access iOS; Android
Interoperability ONVIF 22.06(Profile T; Profile S; Profile G); CGI; SDK
Browser Chrome; IE9 and later; Firefox
Recording Playback
Multi-channel Playback Up to 16 channels
Record Mode General, motion detection; intelligent; alarm
Backup Method USB device and network
Playback Mode Instant playback, general playback, event playback, tag playback, smart playback
Storage
Disk Group Yes
Alarm
General Alarm Motion detection; privacy masking; video loss; scene changing; PIR alarm; IPC external alarm
Anomaly Alarm Camera disconnection; storage error; disk full; IP conflict; MAC conflict; login locked; and cybersecurity exception
Intelligent Alarm Face detection; face recognition; perimeter protection; SMD Plus; people counting; stereo analysis; heat map
Alarm Linkage Record; snapshot; IPC external alarm output; audio; buzzer; log; preset; email
Port
Audio Input 1-channel RCA
Audio Output 1-channel RCA
Alarm Input 4 channels
Alarm Output 2 channels
HDD Interface 2 SATA ports, up to 16 TB.The maximum HDD capacity varies with environment temperature.
RS-232 1
USB 2 (1 front USB 2.0 port, 1 rear USB 2.0 port)
HDMI 1
VGA 1
Network Port 1 (10/100/1000 Mbps Ethernet port, RJ-45)
PoE Port 16 ports, 10/100 Mbps, IEEE 802.3 af/at
General
Power Supply 100–240 VAC, 47-63 Hz
Power Consumption Total output of NVR is <10 W(without HDD) Total output power of PoE is 130W,the maximum output power of asingle port is 25.5W
Net Weight 2.60 kg (5.73 lb)
Gross Weight 3.80 kg (8.38 lb)
Product Dimensions 375.0 mm × 329.3 mm x 53.0 mm (14.76" × 12.96" × 2.09") (W × L × H)
Packaging Dimensions 451.0 mm × 425.0 mm × 147.0 mm (17.75" × 16.73" × 5.79") (W × L × H)
Operating Temperature –10 °C to +55 °C (14 °F to +131 °F)
Storage Temperature –20 °C to +60 °C (–4 °F to +140 °F)
Operating Humidity 10%–93% (RH)
Installation Rack or desktop
Certifications
FCC: 47 CFR FCC Part15, SubpartB, Class A
CE-EMC: EN 55032:2015+A1:2020; EN IEC 61000-3-2:2019+A1:2021; EN 61000-3-3:2013+A1:2019+A2:2021; EN 55035:2017+A11:2020; EN 50130-4:2011+A1:2014
CE-LVD: EN 62368-1:2014




NVR FEATURES
  • 4K Ultra High Definition
  • 16 PoE Camera Inputs
  • Remote Viewing – No Monthly Fees
  • H.265+ High Video Compression
  • 256 Mbps Incoming Bandwidth
  • HDMI and VGA Display Output
  • 2 Hard Drive Bays
